● Proprietary technology in color mixing of LED module.
● High efficiency, excellent homogeneity, tight-controlled consistency in color as well as brightness
● 3 colors to 7 colors can be selected.
● Compact modular design, convenient for lamp design and assembly.
● Advanced and reliable packaging technology, worry-free heat dissipation.
● Suitable for Spot light, Wash light, Beam light, Follow spots and others.
Model | Color | Input Power(W) | Typical Wavelength(nm) | Suggested Gobo Size(mm) | Typical Flux(lm) |
| THL150-5C | R | 21 | 626 | - | 820 |
| G | 30 | 528 | - | 1,250 | |
| B | 26 | 456 | - | 280 | |
| M | 52 | 558 | - | 5,500 | |
| A | 26 | 592 | - | 1,150 | |
| sum. | 155 | - | 22 | 9,000 | |
| THL300-5C | R | 40 | 626 | - | 1,150 |
| G | 55 | 526 | - | 2,600 | |
| B | 50 | 455 | - | 580 | |
| M | 96 | 558 | - | 9,200 | |
| A | 42 | 592 | - | 2,100 | |
| sum. | 283 | - | 30 | 15,630 | |
| THL600-5C | R | 50.4 | 626 | - | 1,900 |
| G | 116 | 524 | - | 4,500 | |
| B | 108 | 455 | - | 1,100 | |
| M | 246.4 | 558 | - | 18,900 | |
| A | 123.2 | 592 | - | 4,300 | |
| sum. | 644 | - | 26 | 30,700 | |
| THL800-5C | R | 60 | 625 | - | 2,000 |
| G | 123 | 526 | - | 5,900 | |
| B | 117 | 455 | - | 1,200 | |
| M | 328 | 558 | - | 27,000 | |
| A | 164 | 592 | - | 5,900 | |
| sum. | 792 | - | 30 | 42,000 | |
| THL1300-5C | R | 101 | 625 | - | 4,000 |
| G | 180 | 526 | - | 9,000 | |
| B | 187.5 | 455 | - | 1,700 | |
| Y | 520 | 558 | - | 39,000 | |
| A | 258 | 592 | - | 9,000 | |
| sum. | 1,246.5 | - | 32 | 62,700 |
